Acteon C50 Intraoral Camera

All you need to see at your fingertips

Read more Enquire now

Remarkable clinical vision with the Acteon C50 intraoral camera


Full HD - Clear and detailed images



Vision Mode - Transcript of natural colours



Auto Focus - Work faster and with better image clarity

  • A more confident final diagnostic
  • Increased case acceptance

  • Straight-forward patient education
  • Great for comparing teeth stain and sharing with patients

  • Ease of use for the clinician
  • Improved patient comfort




Macro Vision - More visibility of fissures and caries



Depth of Field - 5 modes* available in one camera




  • Easier clinical evaluation
  • Enhanced communication between clinician and patient

  • User-friendly product for an improved procedure
  • Quick switch: From one mode to another in a second




Image   Image   Image   Image   Image
Daylight mode   Perio mode   Cario mode

Intraoral mode

  Portrait mode
Record of natural colours for a better interpretation of tooth shade, pathology identification and patient follow-up.  Daylight+ mode enables a high contrast, emphasizing anatomic fissures and details of the dentin structure and depth   Enhancement of dental plaque and gingival inflammation, thanks to chromatic amplification

Caries detection by fluorescence technique by LEDs



Daily dentistry follow-up - Daylight or Diagnostic aid modes help you visualise anatomical details that are invisible to the naked eye or with a mirror, so you can see the difference between before and after care



Orthodontics follow-up - This mode turns off the LED light to capture the patient's face or lateral side, ensuring the best orthodontics follow-up



Fully compatible with Twain, DICOM, Windows, AIS and Mac software








Empowering you to focus on what matters the most: Your patients

  • Increase treatment acceptance - Patients become more involved as they quickly understand the importance of suggested treatment

  • Improved patient communication - Highlight pathologies and explain clinical procedures easily.  Facilitate dialogue to address objections and patient concerns

  • Confident patient relationship - Provide effective treatment planning by saving the images directly in the patient record.  Easily compare images from previous patient visits and monitor progress






"With Acteon imaging and surgical instruments, my diagnosis is fast, and the treatment delivery time is shorter than ever."

Dr Al-Qudah, Jordan
Dentist



"I'm not afraid of going to the dentist anymore. I can recover my oral health in just one painless visit."

Mahmoud
Patient of Dr Al-Qudah



Camera Specifications

Sensor CMOS
Resolution 1920 x 1080px
Sensitivity 2 lux
Frame per second (FPS) 25- 30
Aspect ratio 16/9
Lighting 6 white LEDs and 2 blue LEDs
Focus adjustment Automatic focus or Single focus
4 Visions mode Daylight mode.  If option enabled: Daylight+mode, Perio mode and Cario mode
Depth of field From portrait to macro
Image capture Capture button or footswitch (optional)
Angle of view 75 degrees
Cable length 3m
USB output 3.0
Consumption 4.5W max
Handpiece dimensions L; 200; W: 30; H: 24mm
Handpiece weight 100g
International Protection marking (IP) Dust & waterproofness protection IP53
